Marin Rift Zone EL 1 2026 Electric Bike

More Information
Brand	Marin
Battery	400Wh
Colour	Navy Blue
Suitable for	Everyone
Wheel Size	29-inch

Marin County California is regarded as the birthplace of mountain biking. With niche communities back then shaping what it is today, and with Marin Bikes' inception coming shortly after, the company has deep roots in the sport and now offers many styles of bikes to suit off-roaders and commuters alike.

Skip to the beginning of the images gallery

Marin's all-new Rift Zone EL ("Electric Light") trail eMTBs take everything you love about the Rift Zone formula and repurposes it into bikes that share the capability as the full-powered versions, but in lighter-weight packages. Made possible in part by Bosch's new lightweight Performance Line SX drive unit and CompactTube internal battery, the Rift Zone EL models deliver a decidedly playful ride, with a power delivery so natural you might forget it's an ebike. All of the benefits without the bulk, the Rift Zone EL is the perfect platform for those who don't require the full range and power output of more traditional eMTBs.

Specification

Frame and Forks

Frame: All New Series 4 Alloy Lightweight E, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle
Fork: Marzocchi Bomber Z1 150mm Travel, 29, 110x15 Kabolt Thru Axle, 44mm Offset
Rear Shock: Marzocchi Bomber Air Inline, Custom Tune, 210 x 55mm, 25 x M8 Upper & Lower Mount
Headset: FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2"

Drivetrain

Crankset: E*Thirteen E*Spec Plus, 160mm Length, 34 Tooth
Rear Derailleur: Shimano CUES RD-U6000 GS, 10-Speed
Cassette: Shimano CS-LG300-10, 11-48 Tooth
Chain: Shimano LG500

Braking/Shifting

Shifters: Shimano CUES SL-U6000-10R, 10-Speed
Front Brake: TRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor
Rear Brake: TRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor
Brake Levers: TRP Slate EVO, I-Spec EV Compatible

Wheels

Rims: Marin Aluminium Double Wall, 29" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible
Front Hub: Shimano, 110 x 10 Thru Axle, 32H, CentreLock
Rear Hub: Shimano FHTC500, 148 x 12 Thru Axle, Mircospline, 32H, CentreLock
Spokes: 14 Gauge Black Stainless Steel
Tyres: Front: Maxxis Minion DHF, 29 x 2.5" MAXXGRIP, Tubeless Ready, EXO+, Rear: Maxxis Forecaster 29 x 2.4", Tubeless Ready MAXX TERRA EXO+

Finishing Kit

Handlebars: Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Grips: Marin Grizzly Lock-On
Stem: Marin 3D Forged Alloy, 35mm
Seatpost: TranzX, YSI34 QL, Plastic 1x Remote, Size S 150mm Travel, Size M And L 170mm Travel, Size XL 200mm Travel, 34.9mm
Saddle: Marin Speed Concep Tooth
Pedals: Marin MTB Plastic
