Giant Revolt X 1 2025 Bike
| Brand | Giant |
|---|---|
| Colour | Gloss Panther/Helios Orange |
| Suitable for | Everyone |
| Wheel Size | 700c |
Unlock New Terrain With This Progressive Gravel Bike Featuring Front Suspension. The Lightweight Aluminium Frame Has Suspension-optimised Geometry And A Flip Chip That Lets You Adjust Wheelbase And Tyre Clearance For Any Adventure.
Smooth control
Lightweight aluminium frameset is designed specifically for front suspension. With 40mm of travel, the fork absorbs impacts so you can ride smoother and faster on rugged gravel and dirt.
Tuned compliance
Lowered seatstays with smaller diameter tubes absorb road shocks and vibrations. A Contact SL XR D-Fuse handlebar adds more compliance without sacrificing the stiffness needed for cornering, sprinting or climbing.
Adaptable to the terrain
A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tyres up to 53mm. You can use the included suspension/dropper seatpost for added capabilities, or switch to a proprietary D-Fuse seatpost or traditional 30.9mm round seatpost.
Technology
ALUXX Aluminium Technology
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
D-Fuse Technology
The D-Fuse seatpost and handlebar were designed to function as a system, absorbing road shocks and vibrations so you can ride farther, faster.
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
Flip Chip - Dropout
Allows riders to quickly adjust the geometry and rear-wheel tire clearance with eccentric, offset two-position hardware in the rear wheel dropouts.
Specifications
Frame and Forks
- Frame: ALUXX-Grade Aluminium, 12x142mm Thru-Axle, Disc, Flip Chip Dropout
- Fork: RockShox Rudy XPLR, 40mm, Cartridge Damper, 12x100mm Thru-Axle
Drivetrain
- Shifters: SRAM Apex, 1x12
- Rear Derailleur: SRAM X1 Eagle, 1x12
- Cassette: SRAM PG-1210, 12-Speed, 11x50
- Chain: SRAM CN-EAGL-NX-A1, 12-Speed
- Crankset: SRAM Apex 1 Wide, DUB 1x 40 Tooth
Small: 170mm, Medium: 172.5mm, Medium/Large: 172.5mm, Large: 175mm, Extra Large: 175mm - Bottom Bracket: SRAM DUB, Press Fit
Braking/Shifting
- Brakes: SRAM Hydraulic, Giant MPH Rotors [F]160mm, [R]160mm
- Brake Levers: SRAM Apex 1x12 HRD (Hydraulic Road Disc), Left Lever Dropper Switch
Wheels
- Rims: Giant P-X2 EVO Disc Wheelset
- Hubs: Alloy
- Spokes: Stainless
- Tyres: Crosscut GRIP 700x45c, Tubeless Prepared
Finishing Kit
- Handlebar: Giant Contact SL XR D-Fuse, 31.8mm
Small: 44cm, Medium: 46cm, Medium/Large: 46cm, Large: 48cm, Extra Large: 48cm - Grips: Cork Tape With Gel
- Stem: Giant Contact, 8-Degree
Small: 50mm, Medium: 60mm, Medium/Large: 70mm, Large: 70mm, Extra Large: 80mm - Seat Post: Post Moderne Suspension Dropper, 30.9mm With 30mm Of Suspension
Small: 415mm / 100mm Drop, Medium: 415mm / 100mm Drop, Medium/Large: 415mm / 100mm Drop, Large: 415mm / 100mm Drop, Extra Large: 415mm / 100mm Drop - Saddle: Giant Approach
- Pedals: Pedals Not Supplied
Extras
- Max Tyre Clearance: 53mm Max Tyre Size In "Long" Flip Chip Position, 45mm Max Tyre Size In "Short" Flip Chip Position
- Max Chainring Size: SRAM Wide 2x 43-30, 1x 46 Tooth. Shimano GRX 2x 48-31, 1x 42 Tooth
- Extras: Tubeless Prepared
